The TH-1040-CT is a versatile ceiling mount ideal for medium size (32in-46in) displays. It offers multiple adjustment points, including 360° rotation around the pole, tilt, pan and landscape/portrait display orientation. The telescopic pole enables easy display positioning at the desired height. Installation is simple, with built-in safety features to prevent the telescopic poles separating. Cables are run through the pole for a clean and professional finish. Two options are available:
- TH-1040-CTS - pole adjustment length from 15.75in to 35.43in
- TH-1040-CTL - pole adjustment length from 35.43in to 70.87in
This mount can be upgraded to dual back-to-back or dual vertical configurations (TH-1040-CT-B2B accessory sold separately).
- General Information
- Manufacturer
- Atdec Pty Ltd
- Manufacturer Website Address
- http://www.atdec.com.au
- Brand Name
- Atdec
- Product Type
- Ceiling Mount
- Product Information
- Device Supported
- Flat Panel Display
- Number of Displays Supported
- 1
- Maximum Load Capacity
- 24.95 kg
- Features
- Swivel
- Tilt
- Pan
- 360° Rotation
- Cable Management
- Anti-theft
- Quick Release Mechanism
- Height Adjustable
- Yes
- Physical Characteristics
- Product Color
- Black
- VESA Mount Compatible
- Yes
- Mounting Pattern
- 75 x 75
- 100 x 100
- 200 x 100
- 200 x 200
- Product Material
- Steel
- Plastic
- Aluminium
- Miscellaneous
- Package Contents
- 1 x Ceiling Plate
- 2 x Small/Large VESA Plate
- 1 x Ceiling Plate Cover
- 1 x Plate Assembly
- 1 x Tension Tool
- 4 x Coach Screw
- 4 x Nylon Anchor
- 4 x M4 Washer
- 4 x M5 Washer
- 4 x M10 Washer
- 4 x M4 Spacer
- 4 x M5 Spacer
- 4 x M6 Spacer
- Security Screw
- Set Screw
- 1 x 2.5mm Allen Key
- 1 x 3mm Allen Key
- 1 x 5mm Allen Key
- 4 x M4 x 16mm Display Mounting Screws
- 4 x M4 x 25mm Display Mounting Screws
- 4 x M5 x 16mm Display Mounting Screws
- 4 x M5 x 25mm Display Mounting Screws
- 4 x M6 x 16mm Display Mounting Screws
- 4 x M6 x 30mm Display Mounting Screws
- Additional Information
- Telescopic pole adjustment from: 15.75" - 35.43" (400mm to 900mm)
- Secondary display height adjustment of 12.40" (315mm)
- Portrait to landscape rotation
- Secondary display height adjustment of 12.40" (315mm)
- Ball joint mechanism allows for display angular adjustment of 20 degrees in any direction; portrait to landscape rotation
- Quick release mechanism for easy display attachment/removal with security screw for theft resistance
- 360 Degrees around the pole
- Compatibility
- LCD
- LED
- Assembly Required
- Yes
