The Vertiv Geist F0126849 is a 16A, 230V, 1U horizontal rack power distribution unit (PDU). It has (8) IEC C13 outlets, (2) IEC C19 outlets, and a C20 plug providing 3.6kW in power capacity. It is offered with simple and convenient configuration options for cord lengths and chassis colors. Vertiv Geist Basic Rack PDUs are UL-listed and are not batch-tested. The RoHS-compliant rPDUs undergo rigorous individual tests for reliability and functionality before shipping. The unit comes with a three-year warranty that can be extended to five-years if registered within 120 days of purchase.
- General Information
- Manufacturer
- Vertiv
- Manufacturer Website Address
- http://www.vertiv.com/
- Brand Name
- Vertiv Geist
- Product Series
- rPDU
- Product Type
- PDU
- Warranty
- Limited Warranty
- 3 Year
- Technical Information
- PDU Type
- Basic
- Phase
- Single Phase
- Plug/Connector Type
- IEC 60320 C20
- Plug/Connector Detail
- 1 x IEC 60320 C20
- Receptacle Type
- IEC 60320 C13
- IEC 60320 C19
- Receptacle Detail
- 8 x IEC 60320 C13
- 2 x IEC 60320 C19
- Power Description
- Input Voltage
- 230 V AC
- Input Voltage Range
- 220 V AC - 240 V AC
- Output Voltage
- 230 V AC
- Power Rating (Watt)
- 3.60 kW
- Input Current
- 16 A
- Physical Characteristics
- Mounting Orientation
- Horizontal
- Mount Type
- Rack-mountable
- Cabinet-mountable
- Rack Height
- 1U
- Height
- 44 mm
- Width
- 432 mm
- Depth
- 165 mm
- Miscellaneous
- Package Contents
- rPDU 10-Outlets PDU
- Mounting Brackets
- Environmentally Friendly
- Yes
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS)
